SOH CAH TOA formula: sin = opp/hyp, cos = adj/hyp, tan = opp/adj
The SOH CAH TOA formula is sin θ = opposite/hypotenuse, cos θ = adjacent/hypotenuse, tan θ = opposite/adjacent.
Example: with hypotenuse 15 cm and angle 28°, the opposite side is 15 × sin 28° = 7.04 cm (3 s.f.).
What each letter means
- \(\theta\) the angle you are using (not the right angle)
- \(\text{opp}\) the side opposite θ
- \(\text{adj}\) the side next to θ that is not the hypotenuse
- \(\text{hyp}\) the hypotenuse, opposite the right angle
SOH CAH TOA in Edexcel 4MA1 and Cambridge 0580
| Course | Where it is | Tier |
|---|---|---|
| Edexcel International GCSE Maths A (4MA1) | 4.8 Trigonometry and Pythagoras' theorem | Foundation and Higher Papers 1F and 2F and Papers 1H and 2H |
| Cambridge IGCSE Mathematics (0580) | C6.2 / E6.2 Right-angled triangles | Core and Extended Paper 1 (no calculator) and Paper 3 (calculator) and Paper 2 (no calculator) and Paper 4 (calculator) |
Calculator: Edexcel 4MA1: A calculator may be used in all four papers. Cambridge 0580: No calculator on Papers 1 and 2; a scientific calculator is needed for Papers 3 and 4. Algebraic or graphic calculators are not allowed.
Without a calculator: Every 0580 paper can test any topic. Without a calculator, Extended candidates use the exact values of sin, cos and tan of 30°, 45° and 60° (sub-topic E6.3). 0580 non-calculator papers: what to practise.
When to use it
In a right-angled triangle, when the problem involves an angle and two sides: heights from angles of elevation, slopes, bearings.
Worked examples
1. A right-angled triangle has hypotenuse 15 cm and an angle of \(28^\circ\). Find the side opposite the angle.
- \(\sin28^\circ=\dfrac{\text{opp}}{15}\)
- \(\text{opp}=15\sin28^\circ\)
Answer: 7.04 cm (3 s.f.)
2. The opposite side is 7 cm and the adjacent side is 10 cm. Find the angle, to 1 decimal place.
- \(\tan\theta=\dfrac{7}{10}\)
- \(\theta=\tan^{-1}0.7\)
Answer: \(\theta=35.0^\circ\)
Common mistake
Calculator in radians. Check it shows D (degrees) before you press sin, cos or tan.
Try one yourself
One quick IGCSE Maths question on the SOH CAH TOA (right-angled trigonometry). No sign-in needed.
Get 5 more like this — freeGoogle, Microsoft or email. No card needed.
IGCSE exam-style questions, marked step by step
Our own questions in the style of the 4MA1 and 0580 papers. M1 is a method mark, A1 an accuracy mark that needs the method before it, and B1 a mark that stands on its own. The split is our illustration: how IGCSE mark schemes work.
A ramp rises \(1.2\) m over a horizontal distance of \(7.5\) m. Work out the angle the ramp makes with the horizontal, correct to 1 decimal place.
- Opposite and adjacent are known, so use tan M1 · the right ratio
- \(\tan\theta=\dfrac{1.2}{7.5}=0.16\) M1 · values in
- \(\theta=9.1^\circ\) A1 · answer to 1 d.p.
Answer: \(9.1^\circ\) 3 marks in all
From a point on level ground \(40\) m from the foot of a tower, the angle of elevation of the top of the tower is \(32^\circ\). Work out the height of the tower, correct to 3 significant figures.
- \(\tan32^\circ=\dfrac{h}{40}\) M1 · tan with the values in
- \(h=40\times\tan32^\circ=24.99\ldots\) M1 · rearranged
- \(h=25.0\) A1 · answer to 3 s.f.
Answer: \(25.0\) m 3 marks in all
Where marks slip: Angles of elevation and depression are Higher tier on 4MA1 and Extended on 0580. Writing \(25\) instead of \(25.0\) is not 3 significant figures.
Where IGCSE students lose marks
- Ignoring the 3 s.f. (1 d.p. for angles) accuracy rule. Fix: Unless a question says otherwise, give non-exact answers to 3 significant figures and angles in degrees to 1 decimal place. Write the longer calculator value first, then the rounded answer. (Cambridge 0580 examiner reports)
- Bearings: the wrong angle, or measured from the wrong line. Fix: A bearing is measured clockwise from north and written with three figures. For the reverse bearing add 180° (or subtract 180° if the bearing is more than 180°). Draw the north lines first. (Cambridge 0580 examiner reports)
From our summaries of the published examiner reports: Cambridge 0580.
Revise it for your IGCSE exam
- Notes 0580 notes: C6.2 / E6.2 Right-angled triangles
- Notes 4MA1 Foundation: 4.8 Trigonometry and Pythagoras' theorem
- Practise Skill Builder (4MA1): Trigonometry 1 (free account)
- Practise Skill Builder (0580): Right-angled triangles (free account)
- Papers Edexcel 4MA1 Higher past papers and mark schemes
- Papers Edexcel 4MA1 Foundation past papers
- Papers Cambridge 0580 past papers and mark schemes
- Checklist 4MA1 specification and 0580 syllabus checklists
- Dates IGCSE Maths exam dates (4MA1 and 0580)
On your IGCSE Maths course
| Course | In the exam |
|---|---|
| Edexcel 4MA1 (Higher) | Not given: learn it |
| Cambridge 0580 | Not given: learn it |
From our own IGCSE Maths formula sheets, in our words. Official: Pearson's 4MA1 specification (PDF, Appendix 5) · Cambridge's 0580 syllabus (PDF).
Practise and revise
IGCSE Maths FAQ
Is the SOH CAH TOA (right-angled trigonometry) on the IGCSE formula sheet?
Edexcel 4MA1 (Higher): not given: learn it. Cambridge 0580: not given: learn it.
What does SOH CAH TOA stand for?
Sin = Opposite ÷ Hypotenuse, Cos = Adjacent ÷ Hypotenuse, Tan = Opposite ÷ Adjacent. It only works in right-angled triangles.
Is the SOH CAH TOA formula Foundation or Higher, Core or Extended?
On Edexcel 4MA1 it is in section 4.8 (Trigonometry and Pythagoras' theorem) at Foundation, so it can come up on Papers 1F and 2F and Papers 1H and 2H. On Cambridge 0580 it is in sub-topic C6.2 / E6.2 (Right-angled triangles) for Core and Extended.
Do I need my calculator in degrees for IGCSE trigonometry?
Yes. Both boards use degrees, so check the screen shows D or Deg before a trig question; a calculator in radians gives a wrong answer with no warning.
Can I use a calculator for SOH CAH TOA questions in IGCSE Maths?
Edexcel 4MA1: A calculator may be used in all four papers. Cambridge 0580: No calculator on Papers 1 and 2; a scientific calculator is needed for Papers 3 and 4. Algebraic or graphic calculators are not allowed. Every 0580 paper can test any topic. Without a calculator, Extended candidates use the exact values of sin, cos and tan of 30°, 45° and 60° (sub-topic E6.3).
Our own wording, examples and card, checked by IGCSE Math Revision. Not produced or endorsed by Pearson Edexcel.
