IGCSE Maths 4MA1 Foundation Sequences and Graphs Notes
Revision notes for sequences, functions and graphs at Foundation tier (Papers 1F and 2F, grades 5 to 1). Each sub-topic has what you need to know, the key methods, a common mistake and a worked example. Cover the worked solution and try the example first.
- 2 sub-topics
- Papers 1F and 2F
- Calculator allowed
- Free, no sign-in
Try it first
1 of 5
- Question 1 of 5
- Question 2 of 5
- Question 3 of 5
- Question 4 of 5
- Question 5 of 5
Start with one question on the nth term. Stuck? Take a hint. No sign-in needed.
5 more like this — free accountGoogle, Microsoft or email. No card needed.
3.1 Sequences
What you need to know: term-to-term and position-to-term rules; the nth term of a linear sequence.
- A term-to-term rule says how to get from one term to the next, for example 'add 7'.
- A linear (arithmetic) sequence goes up or down by the same amount each time; that difference is the number in front of n.
- Find the nth term of a linear sequence: dn + (first term − d), where d is the difference.
- To check whether a number is in a sequence, set the nth term equal to it and see whether n is a whole number. For 4, 11, 18, …: 7n − 3 = 100 gives n = 103 ÷ 7 = 14.7…, not a whole number, so 100 is not a term.
- Learn to recognise square numbers 1, 4, 9, 16, … (nth term n²), cube numbers 1, 8, 27, 64, … (n³) and triangular numbers 1, 3, 6, 10, …, which go up by 2, 3, 4, … so they are not linear.
Watch out: For 4, 11, 18, … the nth term is 7n − 3, not n + 7.
Worked example (2 marks, grade 3):
Find an expression for the
- The common difference is 3, so the nth term starts 3n.
- When n = 1, 3n = 3; the first term is 7, so add 4: 3n + 4.
Answer:
Higher tier only: first term a and common difference d, and the sum of an arithmetic series.
Practise: Sequences questions with answers · Unit 3 practice (Foundation) · Higher level: Sequences questions
3.3 Graphs
What you need to know: coordinates and midpoints; reading real-life graphs, including distance–time and speed–time; conversion graphs; gradient and y = mx + c; plotting straight-line and quadratic graphs.
- The midpoint of two points is the mean of the x-coordinates and the mean of the y-coordinates.
- Gradient = change in y ÷ change in x; in y = mx + c, m is the gradient and the line crosses the y-axis at (0, c).
- Plot a graph from a table of values, then join the points: with a ruler for a straight line, with a smooth curve for a quadratic.
- On a distance–time graph the gradient is the speed; a horizontal section means the object has stopped.
- For example, the midpoint of (2, 5) and (8, −1) is ((2 + 8) ÷ 2, (5 + (−1)) ÷ 2) = (5, 2).
- On a conversion graph, go across from one axis to the line, then down (or up) to the other axis. When the line passes through (0, 0), you can convert a value beyond the scale by reading a smaller value and multiplying: if 10 units convert to 8, then 50 convert to 40.
Watch out: Rearrange to y = … before reading the gradient: 2y = 6x + 8 has gradient 3, not 6.
Worked example (2 marks, grade 3):
Find the gradient of the straight line through the points
- Gradient = increase in y ÷ increase in x.
- (11 − 2) ÷ (4 − 1) = 9 ÷ 3 = 3.
Answer:
Higher tier only: cubic, reciprocal and trigonometric graphs, transformations of graphs, gradients by tangents, parallel and perpendicular lines.
Practise: Graphs questions with answers · Unit 4 practice (Foundation) · Higher level: Straight Line Graphs questions · Quadratic and Cubic Graphs questions · Real-Life Graphs questions
